Dehumidifier Fral FSW96.100 With heating coil and three-way valve ON/OFF

FRAME
All FSW units are made of galvanized sheet metal, coated with enamel, hardened at 180 °C with polyurethane powder, to ensure the best resistance to atmospheric agents. The frame is self-supporting.

COMPRESSOR
Rotary compressor.
Compressor features:

High efficiency, ensuring energy-saving operation.

Low noise level, quiet operation.

Use of HFC refrigerant for environmental protection.

High reliability, long life.

COLD CIRCUIT
These units use refrigerant R410a. The cold circuit is manufactured in accordance with ISO 97/23 requirements regarding welding procedures and PED regulations.
The cold circuit consists of:
• drying filter;
• Schrader valve for maintenance and control;
• capillary tube;
• compressor;
• condenser and evaporator made of copper tubes with aluminum fins.

CONDENSATE COLLECTION TANK
Stainless steel tank; condensate drain pipe connection: 3⁄4" internal.

FAN
Centrifugal fan.

AIR FILTER
Made of synthetic materials, washable and easy to replace.

MICROPROCESSOR
The microprocessor controls all the functions of the unit, such as: general operation, automatic defrosting system, alarm management, humidity and temperature regulation (temperature regulation only in models with hot water heat exchanger).

CONTROL PANEL
The electrical panel complies with the electromagnetic compatibility standards (2004/108 EEC) and the electrical safety requirements for low voltage devices 2006/95 EEC.
The electrical panel contains the following components:

Remote control terminals;

Electronic circuit board.
The installation must comply with current safety regulations and laws. If necessary, provide a main disconnector.

TESTS
Tests are carried out to verify the tightness of the refrigeration circuit. Electrical discharges and functional tests.

TECHNICAL STANDARDS
This dehumidifier complies with the essential requirements of the European Community Directives: 2006/95/EC (December 12, 2006) on the safety of electrical equipment intended for use on low-voltage networks; 2004/108/EC (December 15, 2004) on electromagnetic compatibility; 2006/42/EC (May 17, 2006) on the safety of machinery. Conformity is declared in accordance with the following harmonized technical standards: CEI-EN 60335-2-40, CEI-EN 55014-1, CEI-EN 55014-2. We also declare that the product is manufactured in compliance with the applicable RoHS Directive, i.e. 2002/95/EC, transposed into national law by Legislative Decree No. 151 of 25 July 2005. (Article 5).
